CENTRIFUGAL WATER PUMPS

PUMP SOLUTIONS

ANDRITZ

ANDRITZ is a global leading supplier of plants, equipment, and services for hydro power stations, the pulp and paper industry, the metal-working and steel industries. Headquarters: Graz, Austria. Global presence: over 250 production sites and service/sales companies worldwide. Decades of experience in building hydraulic machines and comprehensive process know-how form the basis of the high standard of ANDRITZ pump engineering. ANDRITZ offers everything from a single source from development work, model tests, engineering design, manufacture and project management, to after-sales service and training. ANDRITZ develops and manufactures standard and customized centrifugal pumps for a wide range of different applications and industries.

//www.youtube.com/embed/-nNlHa0dLnA?&autoplay=0&fs=1&loop=0&color=red&wmode=transparentv

Solution Based on Products

Double-suction submersible motor PUMPS, HDM (heavy duty minig) series.

Industries: water. mining, other industries
Design: multi-stage, double suction submersible motor
Head: up to 1,500 m
Flow rate: up to 6,000 m³/h
Pressure: up to 150 bar
Temperature: up to 75 °C
Speed: up to 3,600 rpm

High-pressure pumps, HP series

Industries: water, pulp and paper, power, other industries

Design: multi-stage, high-pressure

Head: up to 630 m

Flow rate: up to 850 m³/h

Pressure: up to 63 bar

Temperature: up to 140° C

Speed: up to 3,600 rpm

Efficiency: up to 90%

Sewage pumps, wet SW series

Industries: water

Design: single-stage, submersible, close-coupled

Head: up to 80 m

Flow rate:up to 2,600 m3/h

Pressure: up to 10 bar

Temperature: up to 40° C

Sewage pumps, dry SD series

Industries: water

Design: single-stage, channel impeller

Head: up to 100 m

Flow rate: up to 10,000 m³/h Free passage:up to 200 mm

Pressure: up to 15 bar

Temperature: up to140°C

Speed: up to 3600 rpm

Multi-stage axial split case pumps. ASPM series

Industries: water, power, other industries

Design: Multi-stage axial split case pumps with various impeller arrangements in single or double flow design Head: up to 1000 m

Flow rate: up to 10 m³/s

Efficiency: Highest efficiency available

Power: up to 40 MW

Self-priming centrifugal pumps AD series

Industries: water, pulp and paper, food, other industries

Design: single-stage, single-flow, semi-open impeller

Head: up to 190 m

Flow rate: up to 9,000 m³/h

Pressure: up to 40 bar

Temperature: up to 200 °C

Effincienty: up to 88%

Sewage pumps, wet SW series

Industries: water

Design: single-stage, submersible, close-coupled

Head: up to 80 m

Flow rate:up to 2,600 m3/h

Pressure: up to 10 bar

Temperature: up to 40° C

Pump as turbines

Industries: power

Design: single-stage and multi-stage; single-flow or double suction; open or closed impeller

Head: up to 80 m

Flow rate: up to 6 m³/s

Out put: up to 2 MW

Medium-consistency pumps MC series

Industries: pulp and paper, food

Design: single-stage, single-flow, semi-open impeller

Consistency: up to 16%

Head: up to 190 m Flow

rate: up to 13.000 admt/d

Pressure: up to 25 bar

Temperature: up to 140 °C

High-pressure pumps, MP series

Industries: water, pulp and paper, power, other industries

Design: multi-stage, closed impellers

Head: up to 950 m

Flow rate: up to 400 m³/h

Pressure: up to 100 bar

Temperature: up to 160 °C

Efficiency: up to 78%

Single-stage certrifugal pumps ACP series

Industries: water, pulp and paper, food, mining, power, other industries

Design: single-stage, single-flow, open and semi-open impeller Head: up to 190 m

Flow rate: up to 9000 m3/h

Pressure: up to 40 bar

Temperature: up to 200° C

Efficiency: up to 40 bar

Single-flow submersible motor pumps, SU series

Industries: water, mining, other industries

Design: multi stage, single suction submercible motor

Head: up to 800 m Flow rate: up to 900 m³/h

Pressure: up to 100 bar

Temperature: up to 75° C

Speed: up to 3.600 rpm

Split case pumps ASP series

Industrie: water, pulp and paper, power, other industries

Design: single-stage, axial split case

Head: up to 250 m

Flow rate: up to 40.000 m³/h

Efficiency: up to 91%

Power: up to 7000 KW

Pressure: up to 25 bar

Temperature: up to 80 °C

Spilit case pumps for hot medium applications ASPH series

Industries: water, pulp and paper, power, other industries

Reference diameter: (DN)100 to1400,DIN EN1092 standard

Pressure calsses: PN16/ PN25, depending on application, size, and material

Head: up to 180 m

Flow rate: up to 30,000 m³/h

Media temperature: up to 180°C

Effincienty: up to 90%

Drive power: up to 7 MW

Vertical line Shaft pumps

Industries: water, power, other industries

Design: radial, mixed flow or axial; adjustable or fixed

Head: Up to 80m(single-stage) up to 120 m (multi-stage)

Flow rate: up to 70.000 m³/h

Power: up to10.000 KW

Efficiency: highest efficiency available

Vertical Submerged pumps SAT/CAT series

Industries: water, pulp and paper, other industries

Design: vertical, submerged single-stage, single-flow, open or vortex impeller

Head: up to 50 m

Flow rate: up to 800 m³/s

Pressure: up to 16 bar

Temperature: up to 60 C

Consistency: up to 6%
